Airmar  |  SKU: B75C-0-L-MM

B75C Low CHIRP Tilted Element Thru-Hull Transducer (Mix & Match)

$79999
Tilt
Selecting Transducer Tilt

Airmar’s low-profile, Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low-frequency band, operating between 40 and 75 kHz, is a deep-water performer, providing excellent coverage and tracking. The B75L transducer delivers up to 35 kHz of total bandwidth in just one installation.

* REQUIRES AIRMAR 600w MIX & MATCH CABLE *

600w CHIRP Transducer (Thru-Hull)
10.0 lb
  • Product Series
    75
  • Transducer Tilt
    0º
  • Sonar
    Power: 600W
    Frequency: Low CHIRP (40-75 kHz)
    Beamwidth: 32° to 21°
    Max Depth (Freshwater): 1100'
    Temperature: Yes
  • Connections
    Airmar 6pin Mix & Match Cable (600w)
    Requires M&M Cable To Your Display
  • Mounting
    Type: Tilted Element Thru-Hull
    Hole Size: 70mm or 2-13/16"
  • Physical
    Usable Shaft Length: 3.75" (95 mm)
    Weight: 3 lbs (1.4 kg)
  • Material
    Bronze
