XDM1000/1

Name: XDM1000/1
Brand: JL Audio
SKU: JLA/010-03112-00
Price: 754.99 USD
Availability: InStock

1000w 1ch Amplifier

$754⁹⁹ $829⁹⁹

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Description

This monoblock subwoofer powerhouse employs our high-speed NexD™ switching technology to achieve unprecedented efficiency and amazing power output from a very compact chassis. The XDM1000/1 generates up to 1000 W of continuous power into a 2 ohm load (14.4V, 1% THD), making it a great choice to drive higher power subwoofer systems.

Designed for car or boat installations, the XDM1000/1 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades.

Intended specifically for subwoofer applications, the XDM1000/1 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz and a defeatable infrasonic filter (30 Hz, 24 dB/oct.). With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), the amplifier's level can be adjusted directly from the driver's seat or captain’s chair.

Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access.

Specifications

Product Series

XDM
MPN

010-03112-00
Physical

Height: 2.05" (52 mm)
Width: 14.73" (374 mm)
Depth: 7.09" (180 mm)
Amplifier Power

Amplifier Type: Class D
Continuous RMS Power:
4Ω @ 14.4v = 600 W x 1
2Ω @ 14.4v = 1000 W x 1
4Ω @ 12.5v = 500 W x 1
2Ω @ 12.5v = 800 W x 1
Amplifier Processing

Frequency Response: 7 Hz - 500 Hz
Signal to Noise Ratio (Highest Rated Power): 83 dB
Signal to Noise Ratio (1 W): 53 dB
THD+N: 1% @ 2Ω
Damping Factor (4Ω): 1000/50 Hz
Damping Factor (2Ω): 500/50 Hz
Amplifier Filters

Input Channel Modes: No
Filter Modes: Off / LPF
Filter Frequency: 50 Hz - 500 Hz
Filter Slope: 12/24 dB/octave
Infrasonic Filter: 30 Hz, Defeatable
Pass-Through Pre Out: Yes (Buffered)
Remote Level Control: Yes
Power

Input: 11-14.5v DC
Minimum Wiring: 4awg
Connectivity

Power Input
Sub Input (RCA)
Preout (RCA)
Remote Input
Sub Output
Other

0
IP Rating

Not Rated
