CM599LH 1-3kW Pocket Mounted Transducer - No Connector
Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 to 3 kW, low and high-frequency transducer. The Chirp-ready CM599LH gives the deep-water performance of the low frequency down to 3000 m (10000') plus the incredible resolution that the high-frequency band delivers.
The CM599LH is packed with a twenty-four-element, low-frequency array that operates at anywhere between 28 and 60 kHz. The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8° to 4°, beamwidth.
Features:
- Depth and fast-response water-temperature sensing
- 2 to 3 kW of power for exceptional deep-water performance
- Low frequency: 28 to 60 kHz
- 23° to 9° port-starboard beamwidth
- 11° to 5° fore-aft beamwidth
- Maximum depth to 3048 m (10000')
- High frequency: 130 to 210 kHz
- 8° to 4° beamwidth
- Maximum depth to 457 m (1500')
- 112 kHz of total bandwidth from one transducer
- Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
- Resin housing with curved-edge design for wet-box installation
- Can be installed in a cavity or welded tank
- Also available as thru-hull external (R509LH) and in-hull (R599LH) mounts
- Patented Xducer ID® technology
Specifications
Specifications
Identification
| MPN | CM599C-LH |
|---|---|
| Barcode | 801769001624 |
General
| Frequency Band | Low-High |
|---|---|
| Functions | Depth, Temperature |
| Material | Urethane |
| Connector | Bare Wire |
| Display Connector | 0 |
| Max Vessel LOA | 8 m (25') and above |
| High Frequency | 130-210 kHz |
| Common Use | Fishing, Commercial Fishing |
| Max Deadrise Angle | Any |
| Tilted Element | No |
| Low Frequency | 28-60 kHz |
| Max Deadrise | Accommodates any deadrise angle based on custom installation |
| Single or Dual Frequency | CHIRP-Ready Dual-Band |
| Country of Origin | USA |
Physical
| Mounting Style | Tank, Cavity, Pocket/Keel Mount |
|---|---|
| Low Frequency Beamwidth | 11°x23°-5°x9° |
| High Frequency Beamwidth | 8°-4° |
| Cable-Length | 15 m (49') |
| Weight | 14.2 kg (31.2 lb.) |
| Max Depth | Low frequency- 3048 m (10000'), High frequency- 457 m (1500') |
Certifications & Protection
| Hull Material | Fiberglass or metal |
|---|
Electrical
| Power Rating | 2-3 kW |
|---|
