Zeus A275L J-180 4" Alternator with Terminal Block
The highest power output alternator in its size/class.
Features:
- Engineered for High Energy Production.
- Suitable for Marine, RV, Military, and Commercial applications.
- Rapidly charges large battery banks.
- Coolest operating temperatures for increased performance.
- It runs 8 - 20% cooler than incumbent alternators due to heat-shedding coatings, a refrigerator on the housing exterior, dual cooling fans, and OEM components.
- It is optimized for performance at idle speeds.
- Reduces the need for a generator by creating additional power with your engine.
- Unleash peak performance with E-Coat/Cerakote. Our advanced coating absorbs less heat, keeping the A275L cooler. This translates to more amperage for sustained periods.
- Use an ARCO Zeus Bluetooth alternator regulator or lithium battery charging for maximum performance.
- SAE J1171 Certified.
- Made in the U.S.A.
Specifications
Specifications
Identification
| MPN | 4022 |
|---|---|
| Barcode | 695845717048 |
General
| MPN | 4022 |
|---|---|
| Barcode | 695845717048 |
Electrical
| System Voltage | 12V |
|---|---|
| Max Output (Cold, 9,000 RPM) | 311A |
| Sustained Cruising Output (Hot, 6,000 RPM) | 227A |
| Sustained Idle Output (Hot, 3,000 RPM) | 198A |
| Cut-In RPM | 1,061 alternator RPM |
| Regulation | External (EX) - terminal block, requires external regulator |
Physical
| Weight | 14.9 lbs / 6.7 kg |
|---|---|
| Mount Type | J-180, 4in Saddle |
| Pulley | 49K6 (6-groove, 49mm) |
| Max Alternator RPM | 19,000 |
| Stator Size | 138mm |
| Frame Size | Large |
| Rotor Poles | 16 |
| Diodes | 6 positive / 6 negative, 50A rated, avalanche |
Cross Reference
| Superseded ARCO P/N | A275L-12-DF4-EX-49K6 |
|---|---|
| APS | 42i-270-14JEXT/STA |
