2356 Water Resistant BusBar - 100 Amp with Cover
Provides secure water-resistant bussing for harsh environments. The single side nesting design allows for wire entry from one side to maximize space.
Features:
- Water-resistant design with standard ring or fork type terminals allows for simple wiring with standard tools.
- Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
- Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
- Insulating cover meets ABYC/USCG insulation requirements
- Tin-plated copper busses and fuse clips
- Includes four write-on circuit labels
- Small format standard and custom labels available
Specifications
Specifications
Identification
| MPN | 2356 |
|---|---|
| Barcode | 632085023560 |
General
| Cover | Yes |
|---|---|
| Continuous Rating | 100A AC/100A DC |
| Bus Material | Tin-Plated Copper C11000 |
| Terminal Screw | 4 x #8-32 |
| Terminal Stud | 1 x #10-32 |
Electrical
| Maximum Voltage | 300V AC/48V DC |
|---|
Physical
| Mounting Holes | Accepts 1/4" (6mm) Screws |
|---|---|
| Wire Size | (1) 8 AWG to 4 AWG - Input/(4) 16 AWG to 10 AWG - Load |
