Description
Description
WeatherDeck™ Water Resistant Fuse Panel
PN: 4304
Color: Gray
Features:
- Panel front rated IP67 when properly mounted with watertight mounting gasket
- IP67 – protected against immersion up to 1 meter for 30 minutes
- Designed for flybridge and open cockpit applications
- Independent label back lighting circuit for remote switching and dimming
- Each panel can be mounted in four different orientations
- Integrated ATO/ATC fuse based circuit protection
- Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.
Specifications
Specifications
Identification
| MPN | 4304 |
|---|---|
| Barcode | 632085043049 |
General
| Weatherproof | Waterproof |
|---|---|
| Positions | 4 |
| Circuit Protection | Fuse |
| Backlit Label | Bicolored LED |
Electrical
| Nominal Voltage | 12v DC |
|---|---|
| Maximum Amperage | 15A @ 12v DC (per circuit) |
| Backlighting Amperage | 10mA/illuminated Circuit |
| Backlighting Voltage | 12v DC |
Certifications & Protection
| Panel Cumulative Rating | 60A |
|---|
Physical
| Height | 4.3" |
|---|---|
| Width | 3.88" |
| Depth | 2.5" |
