Garmin | SKU: GAR/010-02367-02 | Barcode: 753759250638

GPSmap 1223xsv Multi-Function Display

Name: GPSmap 1223xsv Multi-Function Display
Brand: Garmin
SKU: GAR/010-02367-02
Price: 3099.99 USD
Availability: InStock

12" MFD w/ Built-In Sonar

$3,099⁹⁹

Options

GPSmap 1223 Multi-Function Display

12" MFD

GPSmap 1223xsv Multi-Function Display

12" MFD w/ Built-In Sonar

GPSmap 1243 Multi-Function Display

12" MFD w/ Navionics+

GPSmap 1243xsv Multi-Function Display

12" MFD w/ Built-In Sonar & Navionics+

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Description

With its sleek design, powerful processing and upgraded IPS display, this advanced 12" chartplotter/sonar combo integrates seamlessly into your Garmin marine system.

Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP 923xsv also supports 1 kW CHIRP traditional sonar capabilities.

Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.

With its ultrasleek design, vivid sonar color palette and high-resolution 12" in-plane switching display, this large format chartplotter/sonar combo offers improved sunlight readability and wide-angle visibility.

If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them.

Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.

Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm™ digital switching, Garmin Quickdraw™ Community data and more.

Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.

Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.

This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.

Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.

Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.

This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.

Easily integrate with more engines.
Connect to compatible third-party devices with OneHelm™ digital switching.
Easily build your marine system using the best of network connectivity.
Navigate any waters with preloaded mapping and coastal charts.
See below your boat with built-in sonar capabilities.
Manage your marine experience from nearly anywhere.

Specifications

Product Series

GPSmap x3
MPN

010-02367-02
Physical

Dimensions: 12.1” x 8.9” x 3.2” (30.8 x 22.8 x 8.2 cm)
Weight: 6.6 lbs (3.0 kg)
Mounting

Type: Bracket, Flush or Flat
Cutout: 11 5/8" x 7 15/16" (295.4 mm x 201.1 mm)
Power

Input: 10-32v DC
Typical Draw: 1.68 A @ 12v
Max Draw: 3.56 A @ 12v
Screen

Touchscreen: Yes
Type: WXGA
Size: 12.1"
Resolution: 1280 x 800
Sonar

Built-In Sonar: Yes
Port: 12pin
Power: 1kW
Frequencies:
Traditional: Dual Channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
ClearVu: 260/455/800/1000/1200 kHz
SideVu: 260/455/800/1000/1200 kHz
Connectivity

Built-In GPS: Yes - 10Hz
SD Cards: Yes - microSD (2)
Wireless: WiFi, Bluetooth, ANT
Network: Marine Network (2)
NMEA 0183: Yes
NMEA 2000: Yes
J1939: Yes
Analog Video In: Yes
HDMI In: No
HDMI Out: No
USB: Yes
Sonar: Yes - 12pin
Built-In Chart

Basemap
IP Rating

IPx7

Reviews (0)

In The Box

In The Box:

GPSMAP 1223xsv chartplotter
microSD™ card preinstalled
Power cable
NMEA 2000® T-connector
NMEA 2000 drop cable (2 meters)
Bail mount kit with knobs
Flush mount kit with gasket
Protective cover
Trim piece snap covers
Documentation
8-pin transducer to 12-pin sounder adapter cable

Package Dimensions:

Support/Warranty

Product Support:

Subscription Information:

Release Date:

Warranty: 2yr

* ALL WARRANTY IS THROUGH MANUFACTURE *
