Dimensions
Dimensions (H x W x D)
- x 12.99" x 7.87" (- x 330 x 200 mm)
Weight
8.20 lbs (3.72 kg)
Amplifier
Amplifier Class
Class D
Channels
6
Amplifier Power
Rated Continuous (RMS) Power (14.4 V input @ 4 Ohm < 1% THD)
160 W x 6/580 W x 3 (Bridged)
Rated Continuous (RMS) Power (14.4 V input @ 2 Ohm < 1% THD)
290 W x 6
Rated Continuous (RMS) Power (12.5 V input @ 4 Ohm < 1% THD)
-
Rated Continuous (RMS) Power (12.5 V input @ 2 Ohm < 1% THD)
-
Amplifier Processing
Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth) Analog inputs
-
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth) Analog inputs
-
Signal-to-Noise Ratio (Manufacturer Rating)
100 dB (A-weighted, 1 V reference)
Damping Factor @ 4 Ω
130 @ 100 Hz
Damping Factor @ 2 Ω
-
THD+N @ rated power
< 0.06% @ 100 Hz, 4 Ω, 70% rated power
Frequency Response (+0, -1dB)
10 Hz-42 kHz (-3 dB)
Input Voltage Range @ RCA Inputs
0.2-5 V RMS
Input Impedance
10 kΩ
Remote Level Control
-
Remote Level Modes
-
Channel Input Mode Switch
-
Pass-through Preamp Output
-
Source Channel Selection for PreOuts
-
Amplifier Filters
Bass Boost EQ
Yes
Output Polarity Switch
-
Filter Mode(s) Channels 1 & 2
Off, High-Pass or Band-Pass
Filter Slope(s) Channels 1 & 2
12 dB/octave
Filter Frequency Range Channels 1 & 2
50 Hz-500 Hz or 500 Hz-5 kHz
Filter Mode(s) Channels 3 & 4
Off, High-Pass or Band-Pass
Filter Slope(s) Channels 3 & 4
12 dB/octave
Filter Frequency Range Channels 3 & 4
50 Hz-500 Hz or 50 Hz-5 kHz
Filter Mode(s) Channels 5 & 6
Off, High-Pass or Low-Pass
Filter Slope(s) Channels 5 & 6
12 dB/octave
Filter Frequency Range Channels 5 & 6
50 Hz-500 Hz
High-Pass/Low-Pass Full Range Filter
-
HP Variable Crossover Frequency Range
-
LP Variable Crossover Frequency Range
-
Infrasonic Filter
Yes
Detented, Calibrated Filter Potentiometers
-
Electrical
Operating Voltage
11-15 VDC
Current Consumption (idle)
1.8 A
Current Consumption (standby)
0.04 mA
Fuse Rating
-
Recommended Fuse Type(s)
-
Minimum Copper Power/Ground Wire Gauge
-
General
Water/Dust Protection Rating
IPX2 (vertical install, connections facing down)
Operating Temperature Range
-
Protection Circuits
Short-circuit, overload, thermal (auto-reset)
Warranty/Certifications
Certifications
ASTM-B117 salt fog compliant
Warranty
-
