Victron Orion IP67 DC-DC Converter 12/24-50A - 1200W
Description
Description
Orion IP67 DC-DC Converter 12/24-50A - 1200W
Completely encapsulated: waterproof, shockproof, and ignition-protected. Water, oil, or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminum and the electronics are molded in resin.
Completely encapsulated: waterproof, shockproof, and ignition protected
Water, oil, or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminum and the electronics are molded in resin.
Wide input voltage range
With a 15 to 40 Volts input range, a stable output is ensured during surges or sags due to other equipment connected to the same battery.
Protected against overheating
It can be used in a hot environment such as a machine room.
Please contact your dealer for any returns, repairs or support issues related to this product.
Specifications
Specifications
Identification
| MPN | ORI122421226 |
|---|---|
| Barcode | 8719076048534 |
Electrical
| Input Voltage Range | 18-35VDC |
|---|---|
| Output Voltage | 24V +/-3% |
| Max Continuous Current | 50A |
| Rated Power | 1200W |
| Efficiency | 96% |
Physical
| Dimensions | 265 x 127 x 63mm |
|---|---|
| Weight | 2.15kg |
| Enclosure Rating | IP67 |
| Operating Temperature | -40C to +70C (full output up to 40C, derates 3%/C above) |
Reviews (0)
Reviews (0)
In The Box
In The Box
In The Box:
Package Dimensions:
Available Shipping Methods:
Support
Support
* ALL WARRANTY IS THROUGH MANUFACTURE *
