Fusion | SKU: FUS/010-02284-85

Amplificador Apollo de 8 canales

Apollo Series 8-Channel Amplifier

$949⁹⁹

Los gastos de envío se calcularán al momento de pagar.

Product Support

Support Link:

Subscription Information:

Release Date:

Certifications:

Warranty

Warranty: 3 años

Warranty Policy:

* ALL WARRANTY IS THROUGH MANUFACTURE *

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Código de barras: 753759329631

10.0 lb

Prop65

ES LA DIFERENCIA ENTRE ESCUCHAR LA MÚSICA Y SENTIRLA

* Requiere radio con DSP Fusion habilitado *

Product Series

Serie Fusion Apollo
MPN

010-02284-85
Physical

Dimensions:
W: 14.13" (359 mm)
H: 7.06" (180 mm)
D: 1.75" (45 mm)
* Mounting Bracket Adds 5mm To Depth *
Weight: 6.94lbs
Amplifier Power

Amplifier Class: D
Continuous RMS Power:
4Ω @ 14.4v = 150 W x8
4Ω @ 12.5v = Not Rated
2Ω @ 14.4v = 190 W x8
2Ω @ 12.5v = Not Rated
4Ω Bridged @ 14.4v = 580 W x4
4Ω Bridged @ 12.5v = Not Rated
Amplifier Processing

Frequency Range: 20 Hz - 20 kHz
THD+N: <1% @ 2 Ω per Ch.
S/N Ratio (Highest Rated Power): 97 dB
S/N Ratio (1w): 75 dB
Damping Factor:
4Ω: n/a
2Ω: n/a
Amplifier Filters

Fusion DSP
Setup Through Fusion Link App
Power

Power Input: 10.8 V - 16 V DC
Power Draw:
- Stanby: < 5 mA
- On (No Audio): < 1.60A
Fuse: 40 A
Connectivity

Max Wire Size:
Power: 2awg
Speakers: 12awg

Audio Input: RCA
Input Modes: None
Remote Level Control: None
Pass Through Preamp Output: None
Other

* Requires Fusion DSP Enabled Radio *
IP Rating

IPx2
