Blue Sea Systems | SKU: BSS/8693 | Código de barras: 632085086930

Triple Battery Bank Management Panel - 11 Position

Name: Triple Battery Bank Management Panel - 11 Position
Brand: Blue Sea Systems
SKU: BSS/8693
Price: 616.99 USD
Availability: InStock

$616⁹⁹

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Descripción

The Triple Battery Bank Management Panel keeps your engine and house circuits completely isolated, preventing power drain and electrical conflicts. In emergencies, it enables quick cross-connection between isolated battery banks for backup power when needed. Advanced protection circuitry shields your marine electronics from voltage sags and dangerous spikes that occur during engine cranking, extending the life of your navigation, communication, and entertainment systems.

Especificaciones

MPN

8693-BSS
Physical

Dimensions:
H: 8.00" (203.2 mm)
W: 10.50" (266.7 mm)
D: 3.50" (88.9 mm)
Weight: 4.42 lbs (2 kg)
Power

Max Voltage: 32v DC
Continuous Rating: 350 A
Intermittent Rating (5min): 525 A
Cranking Rating: 1000 A
Certifications

Ignition Protected, SAE J1171 Marine, UL 1500
