Blue Sea Systems | SKU: BSS/7700 | Código de barras: 632085077006

ML-RBS - 12v

Name: ML-RBS - 12v
Brand: Blue Sea Systems
SKU: BSS/7700
Price: 348.99 USD
Availability: InStock

$348⁹⁹

Options

ML-RBS - 12v

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

500 Amp magnetic latching switch provides high amperage switching under load, manually or from remote locations

Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing
LED output to remotely indicate switch state - requires optional LED
3∕ 8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance
7∕ 8" (22 mm) stud length accepts multiple cable terminals
Label recesses for circuit identification
Silver alloy contacts provide high reliability for switching live loads

MPN

7700
Physical

Dimensions: 5.47" x 3.75" x 2.03" (138.94 mm x 95.25 mm x 51.56 mm)
Weight: 2.05 lbs (0.93 kg)
Power

Voltage: 12v
Continuous Current: 500 A
Intermittent Current (5min): 700 A
Starting Current: 1000 A
Connectivity

Stud: 3/8" - 16
IP Rating

IP66
Certifications

Ignition Protected, CE, ISO 8846, SAE J1171
