Abyss Battery 24v 90ah LifePO4 Lithium Battery
Descripción
Descripción
When time on the water matters, capacity is everything.
The ABYSS® 24V 90Ah Lithium Trolling Motor Battery is built for anglers who refuse to cut the day short. Designed with extended runtime and uncompromising performance in mind, this Group 31 powerhouse delivers significantly more capacity than standard systems—without the added weight or complexity of traditional setups.
Replacing dual 12V lead-acid or AGM batteries, this advanced lithium solution provides a cleaner, lighter, and more efficient power system with consistent voltage output from start to finish. No drop-off. No sluggish performance late in the day. Just reliable power when you need it most.
Whether you're fishing long tournaments, pushing through heavy current, or running electronics alongside your trolling motor, the 24V 90Ah is engineered to handle higher demand and longer durations with ease.
Built for real-world marine conditions, it thrives in harsh environments, variable temperatures, and continuous use.
Specifications
Specifications
Identification
| MPN | AB-24V90-BT |
|---|
24V 90Ah Battery Datasheet
| Nominal Voltage | 25.6V |
|---|---|
| Nominal Capacity | 90Ah |
| Parallel Connection | Maximum 4 units |
| Series Connection | No |
| Bluetooth Management System (BMS) | 8S 100A (Available on Android/iOS) |
| Charge Voltage | 28.8±0.4V |
| Standard Charge Current | 30A |
| Fast Charge Current | 90A |
| Max. Continuous Discharge Current | 100A |
| Peak Discharge Current | 200A (10s) |
| Discharge Cut-off Voltage | 20V |
| Cycle Life | 4000 cycles @ 95% Depth of Discharge (DOD) and 6000 cycles @ 80% DOD |
| Self Discharge Rate | Less than 3% per month |
| Charge Efficiency | 100% @0.2C |
| Discharge Efficiency | 98-100% @1C |
| Operating Charge Temperature Range | -20°C to 55°C (-4°F to 131°F) |
| Operating Discharge Temperature Range | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature Range | 0°C to 45°C (32°F to 113°F) |
Physical Specifications
| Dimensions | 12.95" x 6.77" x 8.43" in (329×172×214mm, Group 31) |
|---|---|
| Approximate Weight | 33.91 lbs (15.38 Kg) |
| Terminal Type | M8 |
| Case Color/Material | Black Plastic case (ABS) |
| IP Rating | IP67 |
| Cell Type | Cylindrical LiFePO4 EVE 15Ah (UL Cell) |
| Cell Holder | Yes |
Additional Information
| Features | Bluetooth connectivity for monitoring via Android and iOS devices; Built-in internal heating for cold weather performance |
|---|---|
| Certifications | UL 1642, IEC62133, IEC62619, CE, UN38.3, ROHS |
