2356100 - Water Resistant 100A Busbar with Cover
Water-resistant bussing for harsh environments. Built with wing screws for toolless access.
Features:
- Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
- Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
- Meets ABYC/USCG insulation requirements
- Tin-plated copper busses and fuse clips
- Includes four (4) write-on circuit labels
- Small format standard and custom labels are available
- Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Specifications
Specifications
Identification
| MPN | 2356100 |
|---|---|
| Barcode | 632085235611 |
General
| Cover | yes |
|---|---|
| Terminal Stud | 1 x #10-32 |
| Continuous Rating | 100A AC or DC |
| Bus Material | Tin-plated Copper |
| Terminal Screws | 4 x # 8-32 |
Electrical
| Maximum Voltage | 300V AC - 48V DC |
|---|
Physical
| Mounting Holes | Accepts 1/4" (6mm) screws |
|---|---|
| Wire Size | Load - (4) 16 AWG to 10 AWG |
