Programable ACR - Triple Battery (12v)

Prevents Dead Start Batteries and Ensures Starting Capability by sharing charging on either of three (3) batteries and isolating batteries when no charge sources are present.

Reduces Off-State Quiescent Current by 90% in Three Battery Bank Systems by incorporating two independent charge relays with one ultra-low power draw monitoring system.

Fully Sealed with Integrated Connector solves control wire corrosion and vibration issues related to competitive industry solutions. Enables plug and play assembly.

Ultra-Low Power Draw Compare to typical ACRs (7-10 mA) vs 7610 ACR @ 1.3 mA, will not deplete batteries even after extended electrical system downtime.

Optional Under-Voltage Lock-Out provides ability to prevent either ACR from connecting a good battery under charge with a battery that has a shorted cell, ensuring a single battery or bank will not deplete the other system batteries.

Start/Engine Isolation and Start Assist functions are optional for each relay; allowing protection of sensitive electronics from engine starting events or the option to boost cranking effectiveness.

Adjustable Off-Voltage for Auxiliary Battery Priority provides ability to share start battery energy for auxiliary without risking engine starting ability.

Additional Low Amp Output can be used to report device status remotely, or drive a secondary relay for charge to a battery bank without a charge source (see examples)

In The Box:

Auto Charge Relay
Harness
Documentation

Package Dimensions:

Product Support: EGIS 7612 Product Help

Subscription Information:

Release Date:

Warranty: 4yr

* ALL WARRANTY IS THROUGH MANUFACTURE *
