Garmin | SKU: GAR/010-02596-50 | Código de barras: 753759307066

ECHOmap UHD2 75cv + GT20 Transducer

Name: ECHOmap UHD2 75cv + GT20 Transducer
Brand: Garmin
SKU: GAR/010-02596-50
Price: 649.99 USD
Availability: InStock

7" Chartplotter w/ Canada Charting & Transducer

$649⁹⁹

Options

ECHOmap UHD2 73cv + GT20 Transducer

7" Chartplotter w/ US Inland Charting & Transducer

ECHOmap UHD2 74cv

7" Chartplotter w/ Navionics+ Charting

ECHOmap UHD2 75cv + GT20 Transducer

7" Chartplotter w/ Canada Charting & Transducer

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Descripción

WHY TALK TO A LOCAL WHEN YOU CAN FISH LIKE ONE?

They say locals know best. But anyone who says that hasn’t fished with the ECHOMAP UHD2 5” and 7” chartplotters with clear, crisp sonar and mapping.

The bright 5” or 7” keyed display is made for convenience.

Get double the views¹ with Garmin CHIRP traditional and ClearVü scanning sonars.

What’s under the water looks even better with high-contrast vivid color palettes.

Wi-Fi^® connectivity² between compatible chartplotters makes it easy to share info.

Especificaciones

Product Series

ECHOmap UHD 2
MPN

010-02596-50
Physical

Dimensions: 8.6" x 5.6" x 3.2" (21.8 x 14.2 x 8.1 cm)
Weight: 2.2 lbs (1.0 kg)
Mounting

Type: Bracket or Flush
Cutout: 8 1/16" x 4 11/16" (204.5 mm x 118.7 mm)
Power

Input: 9 - 18v DC
Typical Draw: 1.52 A @ 12v
Max Draw: 3.2 A @ 12v
Screen

Touchscreen: No
Type: WVGA, TN
Size: 7.0"
Resolution: 800 x 480
Sonar

Built-In Sonar: Yes
Power: 500 W
Frequencies:
Traditional: single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
ClearVü: 260/455/800/1000/1200 kHz
Connectivity

Built-In GPS: Yes - 5 Hz
SD Cards: Yes - microSD (1)
Wireless: WiFi
Network: Marine Network
NMEA 0183: No
NMEA 2000: Yes
J1939: No
Analog Video In: No
HDMI In: No
HDMI Out: No
USB: No
Sonar: Yes - 8pin
Built-In Chart

Garmin Navionics+ Canada
IP Rating

IPx7

Reseñas (0)

In The Box

In The Box:

ECHOMAP UHD2 75cv
GT20-TM transducer
Power cable
Tilt/swivel mount with quick release cradle
Protective cover
Hardware
Documentation

Package Dimensions:

Support/Warranty

Product Support:

Subscription Information:

Release Date:

Warranty: 2yr

* ALL WARRANTY IS THROUGH MANUFACTURE *

⚠️ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
