Garmin Signal™ VHF 400 Marine VHF Radio w/Built-In AIS Transponder

Name: Garmin Signal™ VHF 400 Marine VHF Radio w/Built-In AIS Transponder
Brand: Garmin
SKU: GAR/010-02951-00
Price: 1499.99 USD
Availability: InStock

SKU: GAR/010-02951-00

$1,499⁹⁹

Same-Day Shipping Checking cutoff…

Options

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Descripción

**As the FCC requires all units sold in the US to be programmed by a qualified technician. After purchase you will receive a form to fill out for programming of your AIS module. A copy of the MMSI Registration or FCC Ship Station License is required along with the vessel master or owner's signature on the completed programming form. **

Signal™ VHF 400 Marine VHF Radio with Built-In AIS Transponder

Stay aware of the water with built-in AIS transmit and receive capabilities. This feature shows you range, course, speed, and the crossing situation of other AIS-equipped vessels around you to help you navigate.

SLEEK DESIGN

The compact and modern design features edge-to-edge glass and takes up minimal space at the helm.

CLEAR AND SIMPLE COMMUNICATION

Eliminate unnecessary radio noise with automated squelch. If you miss a radio message, you can replay it with VHF audio playback. When you need to maintain watch on multiple channels, advanced watch modes make it easy.

STAY CONNECTED

Quickly transmit a distress signal to nearby vessels with the distress button, which uses Class D DSC to automatically send crucial information that can help emergency responders. You can also use the intuitive DSC features to quickly initiate contact with other AIS-equipped vessels; simply select the vessel on the AIS plotter view, and call them with a tap of a button.

EASY TO UPDATE

Configure the radio, program the MMSI number, and get over-the-air software updates with the ActiveCaptain® smartphone app via built-in Wi-Fi® connectivity.

INSTALLATION IS A BREEZE

Installation is simple since VHF/DSC/AIS features only require a single VHF antenna, and the GPS antenna/receiver is built into the unit. Chartplotter integration is seamless via the NMEA 2000® network and Garmin BlueNet™ Network.

ADAPTIVE NOISE CANCELLATION

Advanced noise cancellation uses machine learning algorithms to eliminate wind, wave, and engine noise for our cleanest audio experience.

AUTOMATED SQUELCH

Radio activity is constantly monitored to eliminate unnecessary noise and static. You also have the option for manual fine-tuning.

ADVANCED WATCH MODES

All VHF channels are continuously scanned for activity in the background, allowing you to maintain watch over channel 16 and all your favorite preset channels simultaneously.

VHF AUDIO PLAYBACK

Didn’t catch that message? Replay it with VHF audio playback, and listen to audio messages for up to 3 minutes on any channel.

GENERAL SPECIFICATIONS

Fist Mic: 100 x 60 x 31 mm (3.9" x 2.4" x 1.2")
Inland waterways (ATIS)

VHF RADIO SPECIFICATIONS

VHF intermodulation" More than 75 dB

DSC

AIS

Long-range position reports (Msg 27)

Specifications

Identification

MPN	010-02951-00
Barcode	753759332365

Physical

Unit size	Head Unit: 75 x 160 x 104 mm (3.0" x 6.3" x 4.1")

Electrical

Operating voltage	9.6 - 32 VDC
VHF transmit power (max)	25 W, 1 W (high, low)
AIS power output	5 W

General

Water rating	IPX7
Backlight	1,000 nits
Region	All U.S., Canadian, and International marine channels; NOAA weather channels
Spurious emissions	Less than –80 dBc (at 25 W)
Spurious response	More than 75 dB
Remote Station Support	RM 100 (x5)
Class	SOTDMA Class B

Lighting

Display Type	IPS LCD, capacitive touch
Display Size	3.5" (89 mm)

Performance

Display resolution	640 x 480 pixels
Operating temperature	–20° to 55° C (–4° to 131° F)
VHF frequency range Tx	156.025–162.025 MHz
VHF frequency range Rx	156.025–163.275 MHz
Transmitter frequency tolerance	+/0.3 kHz
Sensitivity (12 dB SINAD)	-118 dBm (-11 dBu/0.28 uV)
Max antenna gain	6 dBi
Sensitivity (1% BER)	-117 dBm (-10 dBu/0.32 uV)
Frequency range	156.025 – 162.025 MHz
AIS Sensitivity (20% PER)	-115 dBm (-8 dBu/0.4 uV)

Audio

Adjacent channel power	More than 70 dB
Adjacent channel selectivity	80 dB

Certifications & Protection

Intermodulation	More than 65 dB

Reseñas (0)

In The Box

In The Box:

Garmin Signal™ VHF 400 head unit
Fist mic
Sun cover
Head unit power and external audio cable with fuse (2 m)
Fist mic power cable with fuse (2 m)
Drop cable for NMEA 2000® network (2 m)
Mounting hardware
Mounting template
Documentation

Package Dimensions:

9" x 9" x 7"
