Roswell  |  SKU: RSW/C920-1834SD  |  Código de barras: 066066234731

R1 650.4

650 W 4-Channel Amplifier

Precio normal $74300

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Descripción

The R1 650.4 marine-grade amplifier, made by Roswell, is everything your boats audio system has always wanted. These stackable amplifiers utilize a 4-channel Class-D design, that puts out 100 watts RMS per channel at 4Ω, and are perfect for powering your R1 6.5″ marine speaker setup.  Easily bridge & tune with the calibrated crossover controls. Because LEDs create lots of noise issues, this amp features differential RCA inputs for maximum noise rejection. The R1 650.4 is built with fully conformal-coated PCB’s and nickel-plated marine-grade wire terminals to ensure their quality.

Especificaciones

  • Product Series
    R1
  • MPN
    C920-1834SD
  • Physical
    Dimensions:
    W: 11.125"
    H: 7.06"
    D: 1.90"
  • Amplifier Power
    Amplifier Class: D
    RMS Power Output: (@ 14.4V)
    - 4Ω: 100 W x 4
    - 2Ω: 165 W x 4
    - 4Ω Bridged: 300 W x2
  • Amplifier Processing
    Frequency Range: 10 Hz - 25 kHz
    THD+N: Not Rated
    S/N Ratio (1w): Not Rated
    Damping Factor:
    4Ω: n/a
    2Ω: n/a
  • Amplifier Filters
    Filter Mode: HPF/LPF/Full
    Filter Frequency: 30 Hz - 300 Hz
    Filter Slope:
    Infrasonic Filter: No
    Bass Boost: Yes (0-18 dB @ 45 Hz)
  • Power
    Power Input: 12v
    Power Draw:
    - Standby: n/a
    - On: n/a
    Fuse: 60 A (30 A x2)
  • Connectivity
    Audio Input: RCA
    Input Sensitivity: 0.2 - 10.0 V
    Input Modes: Yes (2ch/4ch)
    Remote Level Control: No
    Pass Through Preamp Output: Yes

    Max Wire Size:
    - Power: n/a
    - Speakers: n/a
  • IP Rating
    Not Rated

Reseñas (0)

In The Box

In The Box:

Amplifier
Documentation

Package Dimensions:

  • 14"
  • 11"
  • 3"

Support/Warranty

Product Support:

Subscription Information:

Release Date:

Warranty: 3yr



* ALL WARRANTY IS THROUGH MANUFACTURE *
