GPSmap 8612 (G3) Multi-Function Display

Name: GPSmap 8612 (G3) Multi-Function Display
Brand: Garmin
SKU: GAR/010-02092-01
Price: 3599.99 USD
Availability: OutOfStock

12" MFD w/ BlueChart G3

$3,599⁹⁹

Los gastos de envío se calcularán al momento de pagar.

DISCONTINUED

Limited To Stock Available

Discontinued:

The GPSMAP® 8612 chartplotter features a 12" full HD in-plane switching touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. Experience superior connectivity and networking solutions with complete control of your entire system, right at your fingertips. The device is preloaded with Garmin BlueChart G3 coastal charts and inland mapping that feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) for helping you get where you need to go. Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. The chartplotter includes a premium-performance processor for our fastest map drawing, superior networking, video distribution and more. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or mounted flush. NMEA 2000® networking and the Garmin Marine Network allow you to build your full marine electronics suite — from radar and autopilots to cameras and instruments — controlled from your chartplotter and shared across multiple screens. With SmartMode™ station controls, everything is designed to give you quick, one-touch access to the information you need to ease high-stress situations such as docking. For full control of your boat on your chartplotter screen, use our exclusive OneHelm™ feature to connect to many compatible third-party devices. Built-in Garmin SailAssist™ features provide data, displays and prerace guidance needed to gain a competitive edge. Download the ActiveCaptain® smartphone app to your smartphone or tablet to manage your marine experience from anywhere — from trip planning and prefishing to purchasing, downloading and updating maps.

Product Series

GPSmap 8000
MPN

010-02092-01
Physical

Dimensions: 11.9" x 8.5" x 3" (30.3 cm x 21.6 cm x 7.6 cm)
Weight: 6.0 lbs (2.7 kg)
Mounting

Type: Bracket, Flush or Flat
Cutout: 11 9/16" x 7 3/8" (292.9 mm x 187.9 mm)
Power

Input: 10-32v DC
Typical Draw: 1.3 A @ 12v
Max Draw: 6.0 A @ 12v
Screen

Touchscreen: Yes
Type: FHD, IPS
Size: 11.6"
Resolution: 1920 x 1080
Sonar

No (Requires Sonar Module or Networked XSV Unit)
Connectivity

Built-In GPS: Yes - 10 Hz
SD Cards: Yes - microSD (2)
Wireless: WiFi, Bluetooth, ANT+
Network: Marine Network Large (2)
NMEA 0183: Yes (Requires Accessory)
NMEA 2000: Yes
J1939: Yes
Analog Video In: Yes
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Sonar: Yes - 8pin / 12pin
Built-In Chart

Garmin BlueChart G3
IP Rating

IPx7
