Raymarine | SKU: RAY/T70266 | Código de barras: 723193813461

Q24C Quantum - 15m Power/Data Cable

Name: Q24C Quantum - 15m Power/Data Cable
Brand: Raymarine
SKU: RAY/T70266
Price: 2189.99 USD
Availability: InStock

18" Wi-Fi Dome Radar w/ 15m Cables

$2,189⁹⁹

Options

Q24C Quantum - 10m Power Cable

18" Wi-Fi Dome Radar w/ 10m Cable

Q24C Quantum - 10m Power/Data Cable

18" Wi-Fi Dome Radar w/ 10m Cables

Q24C Quantum - 15m Power/Data Cable

18" Wi-Fi Dome Radar w/ 15m Cables

Need This Product Installed?

We Offer Mobile Installation From West Palm Beach - Fort Pierce, FL

Click Here To Set Up Your Installation

Descripción

Quantum radar technology brings you exceptional short-range detection and remarkable target detail with a minimal 18' (6m) range. The use of CHIRP Pulse compression technology means that more energy is delivered to targets, ensuring that you get superior imaging even at long distances.

Ideal for a variety of vessels, including sailboats, RIBs, and smaller powerboats, Quantum offers broad utility. Installation is a breeze, and for those upgrading, existing cables can be repurposed with a simple adapter, making Quantum a convenient and versatile choice.

Especificaciones

Product Series

Quantum
MPN

T70266
Physical

Dimensions:
Dia: 21.29" (541 mm)
H: 8.24" (209.5 mm)
Weight: 12.34 lbs (5.6 kg)
Power

Input: 10.8-31.2v DC
Standby Draw: 7 W
Transmit Draw: 17 W
Radar

Type: X-Band Pulse Compression Solid State
Power: 20 W
Beam Width: 4.9° x 20°
RPM: 24
Max Range: 24nm
Min Range: 18' (6 m)
Connectivity

Wi-Fi
Cable Length (Ft)

49
IP Rating

IPx6
Certifications

47CFR, FCC Part 2, FCC Part 80

Reseñas (0)

In The Box

In The Box:

Radar
Power Cable
Mounting Hardware
Documentation

Package Dimensions:

Support/Warranty

Product Support:

Subscription Information:

Release Date:

Warranty:

* ALL WARRANTY IS THROUGH MANUFACTURE *

⚠️ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
